VertexSeal Flash

FLEXIBLE. DURABLE. LEAD-FREE.

SHAPE & SEAL WITH CONFIDENCE
Product Copy for Packaging
Product Introduction: VertexSeal Flash is a high-performance, lead-free flashing
solution designed for professional roofing applications. Engineered with a durable, UV-
resistant Polyisobutylene (PIB) surface and an integrated aluminum mesh core, it is
exceptionally flexible and easy to shape. It provides a permanent, watertight seal,
offering a safer and more efficient alternative to traditional lead flashing.
Key Features
 100% Lead-Free & Non-Toxic: Safe for installers and the environment.
 Highly Flexible: Embedded aluminum mesh allows for easy shaping by hand to
fit any roof profile.
 Durable & UV Resistant: PIB surface ensures long-lasting performance against
weather and sun exposure.
 Lightweight: Easy to handle, transport and install.
 Excellent Adhesion: Creates a strong, permanent bond to most building
materials.
Applications – Ideal for creating a weatherproof seal on:
 Chimney and wall abutments
 Skylights and roof windows
 Pipe and vent penetrations
 Roof valleys and ridges
 Side and front aprons
Installation Guide
1. PREPARE: Ensure the surface is clean, dry and free from dust, oil or grease.
2. CUT: Cut the flashing to the required length and width.
3. SHAPE: Mold the flashing to the profile of the roof. Use your hands or a roller for
a snug fit.
4. ADHERE: Peel back the release liner. Press the flashing down firmly from the
center outwards to eliminate air pockets and ensure a complete seal.
Technical Information
 Material: Polyisobutylene (PIB) with integrated aluminum mesh
 Standard Widths: 11 inches / 14.5 inches / 22 inches
 Roll Length: 16.4 feet
 Colors:
o Graphite Black (RAL 9011)
o Copper Brown (RAL 8004)
o Window Gray (RAL 7040)
o Mouse Gray (RAL 7005)
o Gray Brown (RAL 8019)
o Traffic Gray (RAL 7043)
o Custom colors available upon request.

Storage
 Store flat in original packaging in a cool, dry place.
 Keep away from direct sunlight or other heat sources.
Precautions
 For best results, apply in temperature environments between 41°F to 104°F.
 A primer may be required for porous surfaces like concrete or masonry.

VertexSeal Flash

 Always wear appropriate personal protective equipment (PPE), including gloves
and safety glasses.
